Plasma Laser Cutting and Surfacing Central Dust Collector
Plasma Laser Cutting and Surfacing Central Dust Collector
Plasma Laser Cutting and Surfacing Central Dust Collector
Plasma Laser Cutting and Surfacing Central Dust Collector
Plasma Laser Cutting and Surfacing Central Dust Collector
  • Plasma Laser Cutting and Surfacing Central Dust Collector
  • Plasma Laser Cutting and Surfacing Central Dust Collector
  • Plasma Laser Cutting and Surfacing Central Dust Collector
  • Plasma Laser Cutting and Surfacing Central Dust Collector
  • Plasma Laser Cutting and Surfacing Central Dust Collector

Plasma Laser Cutting and Surfacing Central Dust Collector

    Payment Type: L/C,T/T,D/P,Paypal
    Incoterm: FOB,CFR,CIF,EXW,CIP
    Min. Order: 1 Set/Sets
    Delivery Time: 15 Days

Basic Info

Model No.: MLWF1000

Type: Filter Cartridge Dust Collector

Power: 11kw

Weight: 1600kg

Air Volume: 9000-12000 M³/h

Filter Area: 145m²

Additional Info

Packaging: Box

Productivity: 100sets/Month

Brand: Moland

Transportation: Ocean,Land

Place of Origin: Jinan City, Shandong Province, China

Supply Ability: 100sets/Month

Certificate: CE, ISO9001,ISO14001

HS Code: 8421399090

Port: Qingdao

Product Description


Industrial Dust Collector for Laser and Plasma Cutter Fume Extractor


Part 1: dust collector for plasma cutting application
Plasma cutting is different from Welding or laser cutting. It have more fume during working. Choosing one good quality dust collector is very meaningful. Moland can offer the most effective solution according to the working condition, and decrease the plasma fume damage to production.


Dust purifier
· Suitable for: welding fume, cutting fume dust, laser welding cutting fume, plasma cutting fume, polishing dust, drilling dust, mixing and cutting materials to produce

Performance description
· Integral structure, beautiful appearance, small area
· Anti-suction device and all-directional rotor ash cleaning system make the effect of ash cleaning more thorough
· Power supply condition monitoring: alarm for broken phase overvoltage and undervoltage to prevent motor and electrical components from damage
· Pneumatic condition monitoring: alarm of low pressure of air source to prevent incomplete ash cleaning. Pressure differential meter shows the use status of filter element intuitively, and high pressure differential auto-pulsed rotor backblowing
· Operation temperature monitoring: alarm system temperature is too high to prevent fire
· Dust hopper condition monitoring: the system senses the lock state of the dusthopper, with the automatic lifting function of the dusthopper, to ensure that the dusthopper is in place, to
improve the tightness of the dusthopper, and to ensure the effect of dust collection.

Standard configuration
· Filtration efficiency (> 99.9%) of main filter core (imported coated polyester fiber)
· Fault phase protection, overload protection, air pressure monitoring and temperature monitoring devices
· PLC Intelligent Control System
· Tri-color lamp
· Pressure differential gauge
  • Muffler
  • 150L dust collector
  • Left rear air intake
  • 10m power cord
  • Spark catcher Large Particle Dust Prefilter)
Power 11kw
Voltage 380V / 50Hz
Air Volume 9000-12000m³/h
Accuracy 0.3μm
Filter material PTFE Cartridge Filter
Filter Area 145m²
Filter Size ∅325*660mm (18 branches)
Cleaning Automatic dedusting
Noise 75dBA
Size 2750×1550×2800mm
Weight 1600kg





Plasma Cutter Dust Collector

Central Integrated Dust Collector


Looking for ideal Central Dust Collector Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Central Integrated Dust Collector are quality guaranteed. We are China Origin Factory of Plasma Cutter Dust Collector. If you have any question, please feel free to contact us.
