Centralized Welding Fume Exhaust System
Centralized Welding Fume Exhaust System
Centralized Welding Fume Exhaust System
Centralized Welding Fume Exhaust System
  • Centralized Welding Fume Exhaust System
  • Centralized Welding Fume Exhaust System
  • Centralized Welding Fume Exhaust System
  • Centralized Welding Fume Exhaust System

Centralized Welding Fume Exhaust System

    Payment Type: L/C,T/T,D/P
    Incoterm: FOB,CFR,CIF,EXW,FCA,CPT,CIP
    Min. Order: 1 Bag/Bags
    Delivery Time: 15 Days

Basic Info

Model No.: MLWF3000

Dust Collecting Method: Dry

Type: Filter Cartridge Dust Collector

Additional Info

Packaging: Box

Productivity: 100sets/Month

Brand: Moland

Transportation: Ocean,Land

Place of Origin: Jinan City, Shandong Province, China

Supply Ability: 100sets/Month

Certificate: CE, ISO9001,ISO14001

HS Code: 8421399090

Port: Qingdao

Product Description



Dust purifier
· Suitable for: welding fume, cutting fume dust, laser welding cutting fume, plasma cutting fume, polishing dust, drilling dust, mixing and cutting materials to produce

Performance description
· Integral structure, beautiful appearance, small area
· Anti-suction device and all-directional rotor ash cleaning system make the effect of ash cleaning more thorough
· Power supply condition monitoring: alarm for broken phase overvoltage and undervoltage to prevent motor and electrical components from damage
· Pneumatic condition monitoring: alarm of low pressure of air source to prevent incomplete ash cleaning. Pressure differential meter shows the use status of filter element intuitively, and high pressure differential auto-pulsed rotor backblowing
· Operation temperature monitoring: alarm system temperature is too high to prevent fire
· Dust hopper condition monitoring: the system senses the lock state of the dusthopper, with the automatic lifting function of the dusthopper, to ensure that the dusthopper is in place, to
improve the tightness of the dusthopper, and to ensure the effect of dust collection.

Standard configuration
· Filtration efficiency (> 99.9%) of main filter core (imported coated polyester fiber)
· Fault phase protection, overload protection, air pressure monitoring and temperature monitoring devices
· PLC Intelligent Control System
· Tri-color lamp
· Pressure differential gauge
Power 37kw
Voltage 380V / 50Hz
Air Volume 30000-35000m³/h
Accuracy 0.3μm
Filter material PTFE Cartridge Filter
Filter Area 290m²
Filter Size ∅325*600mm (36 branches)
Cleaning Automatic dedusting
Noise 75dBA
Size 3000×1550×2800mm
Weight 1600kg


Smoke and Dust Exhaust System



Welding Smoke Exhaust System
Central Dust Collection System
Central Dust Collection System

Looking for ideal Smoke and Dust Exhaust System Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Welding Smoke Exhaust System are quality guaranteed. We are China Origin Factory of Central Dust Collection System. If you have any question, please feel free to contact us.

Product Categories : Centralized Fume Extraction Systems > Fume Extraction With Hoods
